transmission_astri_window_new#
The full file can be found in the Simulation Model repository here.
The first 30 lines of the file are:
#@RPOL@[ANGLE=] 2
# Note: first line starting with "#@RPOL@" is required for automatic
# 1-D/2-D interpolation and table format switching (default is 1-D).
#
# Angle-dependent transmission for ASTRI camera window.
# Contributed by Giancarlo Cusumano, 2017-09-01,
# with extended wavelength and angular range (w.r.t 2017-07-24 version)
#
# wavelength/nm 12deg 16deg 20deg 24deg 28deg 32deg 36deg 40deg 44deg 48deg 52deg 56deg 60deg 64deg 68deg 72deg 76deg 80deg
#
# y values:
ANGLE= 12 16 20 24 28 32 36 40 44 48 52 56 60 64 68 72 76 80
# x + z values:
280.000000 0.952600002 0.952799976 0.953400016 0.954599977 0.954500020 0.956300020 0.959100008 0.961199999 0.961700022 0.959200025 0.948499978 0.889900029 0.869199991 0.835500002 0.783699989 0.711300015 0.607100010 0.725099981
285.000000 0.944400012 0.944700003 0.947099984 0.950999975 0.954800010 0.960500002 0.966199994 0.970899999 0.972899973 0.968800008 0.951799989 0.888800025 0.865000010 0.825600028 0.770600021 0.696799994 0.597199976 0.720499992
290.000000 0.936999977 0.940400004 0.945699990 0.952799976 0.960300028 0.970099986 0.977199972 0.981500030 0.980400026 0.968999982 0.943000019 0.888899982 0.861500025 0.819999993 0.764800012 0.691100001 0.594500005 0.721199989
295.000000 0.939000010 0.944500029 0.953899980 0.962599993 0.972800016 0.981199980 0.987100005 0.987500012 0.979900002 0.960699975 0.929799974 0.888100028 0.859600008 0.816500008 0.762799978 0.690400004 0.598800004 0.725000024
300.000000 0.951300025 0.958999991 0.968500018 0.977599978 0.985199988 0.991299987 0.991900027 0.986299992 0.972999990 0.950699985 0.916599989 0.888000011 0.858799994 0.817200005 0.763999999 0.695200026 0.605000019 0.726999998
305.000000 0.969399989 0.976199985 0.983500004 0.989700019 0.993700027 0.993499994 0.988499999 0.978399992 0.963500023 0.942099988 0.911000013 0.887300014 0.858900011 0.819000006 0.768700004 0.703000009 0.610899985 0.728999972
310.000000 0.985300004 0.989499986 0.992900014 0.994199991 0.992900014 0.988499999 0.980300009 0.969600022 0.956700027 0.937600017 0.912000000 0.890100002 0.861599982 0.822899997 0.774299979 0.707599998 0.616800010 0.730499983
315.000000 0.992100000 0.992900014 0.992299974 0.989499986 0.984899998 0.978500009 0.971700013 0.963299990 0.953299999 0.938899994 0.917999983 0.889599979 0.864000022 0.829400003 0.778599977 0.713199973 0.617299974 0.731599987
320.000000 0.988699973 0.986500025 0.983299971 0.978999972 0.973699987 0.968599975 0.964500010 0.959699988 0.954100013 0.943700016 0.926299989 0.892400026 0.867699981 0.831300020 0.783999979 0.712599993 0.615700006 0.729499996
325.000000 0.976700008 0.973100007 0.970000029 0.965900004 0.963500023 0.962100029 0.960799992 0.960300028 0.958299994 0.950699985 0.933700025 0.894699991 0.870100021 0.837599993 0.784699976 0.711899996 0.613799989 0.727500021
330.000000 0.961399972 0.958800018 0.956399977 0.954900026 0.954900026 0.957700014 0.959900022 0.964600027 0.963599980 0.956399977 0.937500000 0.896399975 0.873499990 0.839100003 0.784399986 0.713299990 0.609099984 0.723999977
335.000000 0.947799981 0.947799981 0.947300017 0.948899984 0.951799989 0.957799971 0.964200020 0.968400002 0.969099998 0.960500002 0.937099993 0.900799990 0.875400007 0.841899991 0.788200021 0.709900022 0.605199993 0.721800029
340.000000 0.936900020 0.938799977 0.942099988 0.946600020 0.952400029 0.960699975 0.968800008 0.974300027 0.972899973 0.960699975 0.931500018 0.904100001 0.878400028 0.842400014 0.790199995 0.708100021 0.602500021 0.720700026
345.000000 0.931299984 0.935599983 0.941100001 0.947499990 0.954699993 0.965499997 0.973900020 0.977699995 0.973999977 0.957499981 0.924700022 0.907700002 0.882200003 0.843200028 0.787999988 0.707499981 0.601999998 0.721300006
350.000000 0.929799974 0.935100019 0.942499995 0.950699985 0.960600019 0.969600022 0.977500021 0.978900015 0.972000003 0.953700006 0.918299973 0.910399973 0.883499980 0.846000016 0.788699985 0.708299994 0.602199972 0.719200015
355.000000 0.931200027 0.938499987 0.945900023 0.954500020 0.964900017 0.974600017 0.979600012 0.978900015 0.969500005 0.949000001 0.912100017 0.911800027 0.885500014 0.845899999 0.791199982 0.711399972 0.605499983 0.721499979
360.000000 0.935400009 0.942600012 0.950500011 0.959800005 0.968900025 0.977199972 0.980499983 0.977999985 0.966300011 0.944700003 0.908699989 0.911400020 0.885999978 0.847100019 0.791899979 0.714399993 0.610099971 0.722700000
